Fertigation
JET Bypass-III
JET Bypass-III Essential · Professional
A bypass-mode fertigation unit for main pipes carrying 10 to 100 m³/h at up to 7.0 bar, with dual EC and pH sensors and up to 64 irrigation valves.
- Main-Pipe Flow
- 10–100 m³/h
- Main-Pipe Pressure
- ≤7.0 bar
- Irrigation Valves
- ≤64
- Sensors
- Dual EC, pH
What It Is
Overview
JET Bypass-III fertigates large substrate and soil-grown crops in bypass mode.
JET Bypass-III mounts on the main irrigation pipe and works in bypass mode. A booster pump draws water from the fresh-water tank, the unit mixes fertiliser in its mixing chamber, and the dosed water rejoins the main pipe ahead of the flow sensor, filter and irrigation valves.
The Essential edition is a stand-alone unit for main pipes of 10 to 50 m³/h at up to 4.5 bar, with up to 16 irrigation valves and six time-based programmes. The Professional edition can also run as a substation of a central system. It handles 10 to 100 m³/h at up to 7.0 bar, up to 64 valves and unlimited time-based programmes, with laptop control added.
Who It Is ForLarge substrate and precision soil-grown operations, such as flowers and blueberries, that need fertigation on a high-flow main pipe without routing all the water through the unit.
Features
- The German high-precision EC sensor needs no calibration.
- An intelligent pH sensor works alongside the dual EC sensors.
- One unit runs in both direct-injection mode and day-tank mode.
- Operate it from the touch screen, a smartphone or a laptop.
Specifications
Technical Data
JET Bypass-III Specifications
| Parameter | Essential | Professional |
|---|---|---|
| Equipment Type | Stand-alone | Stand-alone / central-system substation |
| Irrigation Type | Fertiliser mixing chamber | Fertiliser mixing chamber |
| Irrigation Mode | Direct injection / day tank | Direct injection / day tank |
| Control | Touch screen + smartphone | Touch screen + smartphone + laptop |
| Dosing Channels | 5 channels, 600 L/h | 5 channels, 600 L/h |
| Sensors | Dual EC, pH | Dual EC, pH |
| Irrigation Valves | ≤16 | ≤64 |
| Irrigation Programmes | Time-based control, 6 programmes | Time-based control, unlimited programmes |
| Main-Pipe Flow | 10–50 m³/h | 10–100 m³/h |
| Main-Pipe Pressure | ≤4.5 bar | ≤7.0 bar |
