HortiECO and HortiMagi
Control runs from the touch screen, a smartphone or a laptop. Laptop control comes with the Professional editions.
Design · Integration · Control · Support
Services
Beyond individual units, OXYGRO designs complete deep water culture greenhouses, connects disinfection and fertigation into one loop, and supports the system once it runs.
01 · DWC Greenhouse Design
A Complete Design for a 10 × 39 m Greenhouse
Layout, tank construction, water systems and a step-by-step installation method for two 36 m deep water culture tanks.
- Two 4 × 36 m tanks, a 2 m harvest walkway and 1.5 m equipment zones.
- 75 mm PU/PIR sandwich-panel tanks: chillers run 60% less than with concrete, and installation labour is 70% lower.
- Aeration, circulation, disc filtration, UV-C, chilling and automated dosing sized for 86,400 L.
Tank Installation Method
Five Steps from Bare Floor to a 36 m Tank
Level the Floor
Laser-level the greenhouse floor.
Anchor the Track
Bolt the 77 mm galvanised floor U-track into concrete or compacted earth with ground anchors every 1 m.
Seal and Set the Panels
Run a bead of polyurethane sealant in the track and drop the 75 mm PU panels in, locking the base of the wall.
Stake Against Bowing
Every 2 m, drive a 40 × 40 mm galvanised stake 600 mm into the ground, flush with the panel, and screw it through.
Cap the Wall
Slide the top U-channel over the panels to lock the whole 36 m run together.
02 · System Integration
Disinfection and Fertigation in One Loop
The ASEPTICER and OXYGRO-Inline are designed to connect, so drain water goes back to the crop instead of to waste.
- The ASEPTICER treats 5–40 m³/h of drain water with 1000 W UV lamps.
- A double butterfly valve blends disinfected and clean water before dosing.
- OXYGRO-Inline Professional offers drain recycling and reuse as an option.
03 · Remote Control and Monitoring
Run Irrigation from the Screen in Your Pocket
Every fertigation unit and the ASEPTICER have a local touch screen and connect to OXYGRO's HortiECO or HortiMagi control software.
Programmes and Recipes
Control ranges from 6 time-based programmes to 20 time- or sensor-based programmes, with unlimited time-based programmes on JET Bypass-III Professional.
Crop Data and Reports
Plant Scale software shows curves and dashboards on computer, mobile and tablet, and produces custom crop reports.
04 · Support
Help When the Crop Needs It
24/7 Technical Support
Technical support is available around the clock.
Agronomists and Engineers
Agronomists and engineers work together on every system.
Trusted Partners
A global network of trusted partners handles supply and service.
Tell Us Your Crop, Area and Flow Rate
Send the details of your site and we will come back with the equipment that fits, with specifications and a quotation.
