Fertigation

JET Inline-II and JET Inline-III

JET Inline-II · JET Inline-III

A mainline fertiliser injector with a jet-type mixing chamber, five dosing channels and German EC/pH sensors, for 15 or 32 m³/h of irrigation flow.

Irrigation Flow: 15 / 32 m³/h
Fertiliser Channels: 5
Inlet / Outlet: DN50 / DN80
Programmes: 6 time-based

What It Is

Overview

JET Inline doses fertiliser on the mainline for soilless crops.

JET Inline sits directly on the irrigation mainline. Clean water passes through a sealed jet-type mixing chamber, where five dosing channels add fertiliser stock to reach the EC and pH set points. A flow sensor and pressure gauge downstream feed the controller, and solenoid valves release the mixed solution zone by zone.

Two sizes share the same design. JET Inline-II has a 2” mixing chamber and DN50 connections for 15 m³/h. JET Inline-III has a 3” chamber and DN80 connections for 32 m³/h. Both run six time-based irrigation programmes in direct or day-tank mode.

Who It Is ForGrowers running soilless crops who need accurate EC and pH dosing on the mainline at 15 to 32 m³/h, in direct or day-tank irrigation.

Features

High-precision EC and pH sensors, imported from Germany, give accurate fertiliser dosing.
A jet-type sealed mixing chamber blends the solution quickly and evenly.
A built-in backwashable outlet filter prevents clogging.
Run it from the touch screen, the HortiECO mobile app or a PC.

Specifications

Technical Data

JET Inline Specifications

JET Inline Specifications
Parameter	JET Inline-II	JET Inline-III
Irrigation Flow	15 m³/h	32 m³/h
Device Type	Mainline	Mainline
Irrigation Mode	Direct / day tank	Direct / day tank
Control	Touch screen + mobile (HortiECO)	Touch screen + mobile (HortiECO)
Fertiliser Channels	5 channels, 200 L/h	5 channels, 300 L/h
EC/pH Sensors	Imported from Germany	Imported from Germany
Mixer	2" jet mixing chamber	3" jet mixing chamber
Irrigation Programmes	6 time-based programmes	6 time-based programmes
Inlet / Outlet	DN50	DN80
